• MODEL 6300 VISIBLE RANGE SPECTROPHOTOMETER OPERATING MANUAL 630 026. • SAFETY Please read this information carefully prior to installing or using this equipment. The unit described in this manual is designed to be operated only by trained personnel. Any adjustments, maintenance and repair must be carried out as defined in this manual, by a person qualified to be aware of the hazards involved. • CONTENTS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SECTION 6 6300 SPECTROPHOTOMETER OPERATING MANUAL INTRODUCTION Instrument Description Instrument Specification INSTALLATION Unpacking Installation Displays Controls Outputs OPERATION Initial Set-Up Sample Measurement Good Practice Guidelines MAINTENANCE General Light Source Replacement OPTIONAL ACCESSORIES Optional Accessories Spares. • SECTION 1 1.1 INSTRUMENT DESCRIPTION The Model 6300 is a microprocessor controlled Visible Range Spectrophotometer covering the wave- length range of 320 to 950nm with a 10nm bandwidth. The monochromator is of a modified Czerny Turner design, incorporating a stepper motor driven 1200 lines/mm holographic diffraction grating and featuring automatic second order response suppression.

• SECTION 2 2.1 UNPACKING Remove the Model 6300 from the packaging and ensure the following items are present: 1. Model 6300 Spectrophotometer 2. Mains Cable 3.

Jenway 6300 Spectrophotometer Service Manual Main Index Section 1 Introduction Section 2 Quick Reference Section 3 System Description Section 4 Optical Description. Of the Jenway Ltd model 6300 Spectrophotometer. (From serial number 5000 upwards, for lower numbers please refer to 6300 Mk1 Manual) This manual must be used in conjunction with the Instruction Manual for this model, as many of the routine maintenance procedures detailed in the Instruction Manual are not repeated in this.

Pack 100 disposable Cuvettes (060 084) 4. Optional Accessories (as ordered) Any shortages or damage should be reported immediately to the Manufacturer or your local Distributor.

• 2.3 DISPLAYS Primary display area - Transmission, Absorbance, Concentration Primary display adjust annunciator Secondary display area - Wavelength, Factor Primary display units Secondary display adjust annunciator Operation with PC Menu options -%T Menu pointers (for 7) ABS CONC FACTOR UNITS 6300/REV B/12-96. • 2.4 CONTROLS used to adjust values on the selected display used to move horizontally between menu options used to select the displayed menu option initiates a calibration routine Print key. Provides a printout of the current reading with an incremental sample number. When pressed for the first time after a calibration the print out will give calibration information. • 2.5 INPUTS/OUTPUTS Fig.

Pc optimizer pro serial keygen download. 2.5.1 Rear Panel Layout 1. LAMP ACCESS PANEL NOTE: The Lamp Access Panel and all ventilation slots must not be covered or obstructed at any time. ROCKER SWITCH 3. POWER IN SOCKET 4. OUTPUT SOCKETS 5.
